U Factor And Shgc Standard French Doors

To access those tables select the individual product of interest and scroll down to the professional resources section.

U factor and shgc standard french doors. This tool gives you the flexibility to select the required energy star zone u factor shgc or vt and determine which milgard window and door products meet the selected requirements. Energy performance data for select combinations of options is available in table format on each product page. In southern climate zones 1 to 3 southern tennessee to the tip of florida there is no u factor cap but the shgc is not to exceed 0 50. In the southern zone skylights must have a u factor of 0 60 or less and an shgc of 0 28 or less.

In the south central zone skylights must have a u factor of 0 53 or less and an shgc of 0 28 or less. Solar heat gain coefficient measures how well a product can resist unwanted direct or indirect solar radiation. This radiation can cause your home to heat regardless of outside temperature which. U factor is the rate at which a window door or skylight conducts non solar heat flow.

Doors are a little different. Solar heat gain and u factor. Glazed doors in hot or temperate climates should have a low shgc. U factor shgc solar heat gain coefficient product type any awning casement double hung fixed casement french door horizontal slider picture window side lite transom single hung sliding glass door storefront door storefront window.

This tool provides some of the most common options on windows and doors and related nfrc certified values. The u factor requirements discussed above for vertical fenestration also apply to exterior glass doors. For windows skylights and glass doors a u factor may refer to just the glass or glazing alone. The u factor of skylights in climate zones 4 to 8 is not to exceed 0 75.

The lower the coefficient the better the glazed door is at blocking the sun s heat. The same shgc cap of 0 50 that applies to vertical fenestration in climate zones 1 to 3 also applies to skylights. The milgard energy calculator provides a quick and easy way to help you select windows and doors that can meet local energy codes and project requirements. Nfrc u factor ratings however represent the entire window performance including frame and spacer material.

South facing glazed doors in cold climates should have a high shgc. It s usually expressed in units of btu hr ft2 of. The circled value shows you the rating a door has received. Each rating is split into two values.
